METROFLEX PANEL HARDWARE

MetroFlex Acoustical Products

METROFLEX ACOUSTIC PANEL HARDWARE:

MetroFlex has a complete line of acoustic panel hardware for installing panels on walls and ceilings.

Impaler Clips

Impaler Clips are 8 pronged steel impaling clips that pierce the backside of frameless acoustic panels for wall installations. 4 Clips per 2x4 Panel

Box of 24 Clips
Bulk Box of 240 Clips
more >>

Prong Push Down Impalers

2-Prong Push Down Impalers are premium impaling clips that hold fiberglass and mineralwool acoustic panels on wall installations. 4 /2x4 Panel

Box of 24 Impalers
more  >>

  MetroFlex Impaler Clips Arrow
  MetroFlex 2-Prong Push Down Impalers Arrow
  MetroFlex Stand-Off Brackets Arrow
  MetroFlex Bass Trap Brackets Arrow
  MetroFlex Z-Clips for Frames Arrow
  MetroFlex Resilient Sound Isolation Clips Arrow


Metro Flex Logo

METROFLEX Acoustical Panel Hardware Options:

Stand Off Brackets

2" Stand-Off Brackets are used to install acoustic panels on walls allowing a 2" air gap between the wall and the panel for superior sound absorption.

8 per box (2 panels)
more >>

Bass Trap Brackets

Bass Trap Brackets are used to install bass trap panels in the corners of studios and theater rooms.

8 per box (2 traps)
more >>

Z Clips

Z-Clips are installed on the back of wood frames and on the wall. The Z-Clips interlock to give a secure install.

24 per box (6 panels)
more >>


Impaling Clips

METROFLEX ACOUSTIC IMPALING CLIPS

Impaling clips are used to easily attach Acoustic Panels to walls. Each clip has 8 spikes that stick into the fiberglass and hold the panel in place. The dimensions of the clips are 2-1/8" x 1-1/2". The impaling clips are installed on the wall by either 1 drywall screw (not included) or attached with adhesive. 4-6 impaling clips are recommended per standard 2' x 4' panel making sure one impaling clip is placed in each corner.

SOLD IN BOXES OF 24

SKU: 65IMPALING

PDF Viewer

Impaler Clips

METROFLEX PUSH DOWN IMPALER CLIPS

Push Down Impaler clips are used for fast and easy installation of acoustic panels to walls. MetroFlex Push Down Impalers are made of galvanized steel and contain two angled prongs per clip (similar to the Bass Trap Impaling Brackets). The impaling clips are installed on the wall by either 1 drywall screw (not included) or attached with adhesive. 4 impaling clips are recommended per standard 2' x 4' panel making sure one impaling clip is placed in each corner.

SOLD IN BOXES OF 24

SKU: 65PUSHDOWN

PDF Viewer

Brackets

METROFLEX BASS TRAP IMPALING BRACKETS

Bass Trap Impaling Brackets clips are used to easily attach Bass Trap Panels to corners of walls to cut off bass sound wave reverberation throughout the room. For each Bass Trap, 4 Brackets must be used (2 Lefts and 2 Rights). The brackets are precision cut on a 45 degree angle and can easily be screwed into the wall through die cut holes. Sold in Sets of 2 (4 Lefts and 4 Rights).

SOLD IN BOXES OF 8

SKU: 65CORNER

PDF Viewer

Impaler Brackets

METROFLEX 2" STAND-OFF IMPALER BRACKETS

2" Stand-Off Impaler brackets are designed for installing Acoustic Panels to walls while providing a 2" air space between the back of the panel and the wall. MetroFlex Stand-Off Brackets are made of galvanized steel and contain four angled prongs per clip. The Stand-Off Brackets are installed on the wall by 2-4 drywall screw (not included). 4 impaler brackets are recommended per standard 2' x 4' panel making sure one stand-off impaler is placed in each corner.

SOLD IN BOXES OF 8

SKU: 65STANDOFF

PDF Viewer

Framed Panels

METROFLEX Z-CLIPS FOR FRAMED PANELS

Z-Clips are used for quick and easy wall installation of acoustical panels with wooden frames. Z-Clips are pressed aluminum with a bend that allows a second opposite Z-Clip to interlock and sit snug in place. Two Z-Clips are fastened into the top of the panel frame (facing downward and out) and two other clips are fastened evenly on the wall (upward and out). The panel then sits on the Z-Clips on the wall. Z-Clips make it very easy to line up multiple panels on one wall at the same height.

SOLD IN BOXES OF 24

SKU: 65ZCLIP

Isolation Clips

METROFLEX RESILIENT SOUND ISOLATION CLIPS

Sound Isolation Clips are used to decouple new drywall from the existing wall studs/ceiling joists. The Resilient Sound Clips are screwed into the wood or metal studs and hold drywall furring channel in place. The drywall sheets are then installed over the furring channel which limits the amount of contact between the new drywall and the existing wall/ceiling. MetroFlex Reslient Sound Clips reduce the amount of sound vibration transmission through the wall/ceiling structure, creating a more sound resistant barrier.

SOLD PER CLIP

SKU: 65RSIC

PDF Viewer

Joist Isolators

METROFLEX FLOATING FLOOR JOIST ISOLATORS

Floating Floor Joist Isolators are used to soften the connection between subflooring and the floor joists. These 2" wide pieces of EPDM rubber are designed to clip onto the bottom of a stud or joist by friction (no use of a fastener). Rubber Joist Isolation clips are used primarily in floating floors of home theaters and sound studios to decouple the new floor from the subfloor.

SOLD PER PIECE OR BOX OF 50

SKU: 65FLOAT
